EchoNavigator
Live echo and live X-ray fusion tool
EchoNavigator
Live echo and live X-ray fusion tool
EchoNavigator automatically fuses live 3D TEE and live X-ray in real time. The solution assists heart teams with intuitive image guidance during procedures where both real-time X-ray and echo imaging are used and fused together.
Clinical image gallery
- View XRay image with markers for context and guidance
Features
Additional reference point through TEE cone
The TEE field of view (cone) is displayed as an outline to give you an additional reference point while working. 3D transesophageal echocardiography (TEE) imaging provides critical insights into soft tissue anatomy.
Always the same orientation and perspective
The TEE transducer position and orientation are automatically tracked in the X-ray image, allowing the echo and the X-ray image to move in sync when the C-arm is repositioned.
Three perspectives for enhanced vizualisation of situation
Up to three different echo views of anatomical structures can be shown simultaneously to enhance vizualisation of soft tissue anatomy and the device location.
